32317 Tapered Roller Bearing
*Dimensions: 85x180x63.5 mm
*Weight: 6.85 kg
*If you wants to know more 32317 bearing,email:alita@sgsabearing.com
Send Inquiry
Product Details of32317 Tapered Roller Bearing
Product datasheet
|
|
Bearing name | 32317 |
| Product classification | Tapered Roller Bearing | |
| Bore diameter-d | 85 mm | |
| Outside diameter-D | 180 mm | |
| Total Width-T | 63.5 mm | |
| Shoulder diameter inner ring -d1 | 127 mm | |
| Width of inner ring-B | 60 mm | |
| Width of outer ring -C | 49 mm | |
| Fatigue load limit | 60 KN | |
| Basic dynamic load rating | 435 KN | |
| Basic static load rating | 530 KN | |
| Reference speed | 2600 r/min | |
| Limiting speed | 3800 r/min | |
| Mass bearing |
6.85 kg |
Products Description
Brand: SKF, SDVV,FAG,TIMKEN
Shipping method: Express, air, sea, railway. from China to every corner of the world.
How to use: Need to be installed in pairs
applications:
1). Heavy machinery: mining equipment, rolling mill gearbox.
2). Transportation equipment: truck wheel hub, railway vehicle axle box.
3). Industrial transmission: reducer, machine tool spindle support
Notes:
1). Avoid direct knocking during installation, use hydraulic tools or induction heating.
2). Monitor temperature rise and vibration regularly, abnormal values may indicate lubrication failure or poor alignment.
